Power Deposition in a Spherical Model of Man Exposed to 1-20-MHz Electromagnetic Fields

Bioeffects Seen

James C. Lin, Arthur W. Guy, Curtis C. Johnson · 1973

Share:

1973 research showed human bodies absorb minimal energy from 1-20 MHz frequencies, but focused only on heating effects.

Plain English Summary

Summary written for general audiences

This 1973 theoretical study used spherical models to calculate how much radiofrequency energy the human body absorbs when exposed to electromagnetic fields between 1-20 MHz. The research found that at these frequencies, the body absorbs very little energy - less than 0.025 milliwatts per gram of tissue for typical exposure levels. The findings suggested that thermal safety limits for these lower frequencies could be much higher than the 10 mW/cm² standard used for microwaves.

Why This Matters

This foundational study established early theoretical frameworks for understanding how the human body absorbs electromagnetic energy at HF frequencies (1-20 MHz), which include amateur radio, shortwave broadcasts, and some industrial heating applications. What makes this research particularly significant is Lin's finding that magnetic field measurements are crucial for assessing exposure hazards in this frequency range - something that's often overlooked in modern EMF assessments that focus primarily on electric fields.

The study's conclusion that thermal safety levels could be "many orders of magnitude" higher than microwave standards reflects the lower absorption rates at these frequencies. However, this thermal-only perspective predates decades of research showing biological effects can occur well below heating thresholds. While Lin's absorption calculations remain scientifically valid, our understanding of EMF health effects has evolved far beyond simple heating models to include non-thermal mechanisms that weren't considered in 1973.

Exposure Information

Specific exposure levels were not quantified in this study.

Cite This Study
James C. Lin, Arthur W. Guy, Curtis C. Johnson (1973). Power Deposition in a Spherical Model of Man Exposed to 1-20-MHz Electromagnetic Fields.
Show BibTeX
@article{power_deposition_in_a_spherical_model_of_man_exposed_to_1_20_mhz_electromagnetic_g4288,
  author = {James C. Lin and Arthur W. Guy and Curtis C. Johnson},
  title = {Power Deposition in a Spherical Model of Man Exposed to 1-20-MHz Electromagnetic Fields},
  year = {1973},


}

Quick Questions About This Study

The study examined the entire 1-20 MHz range, which includes amateur radio, shortwave broadcasting, and industrial heating frequencies. The researchers used theoretical spherical models to calculate energy absorption across this spectrum.
According to the theoretical calculations, a 70-kg person absorbs less than 0.025 milliwatts per gram of tissue for each milliwatt per square centimeter of incident 20 MHz radiation - a very low absorption rate.
The study found that when field impedance is less than 120π ohms, magnetic field-induced energy absorption dominates over electric field effects. This means measuring only electric fields would underestimate the actual exposure hazard.
Lin used theoretical spherical models of varying sizes to represent the human body, combining quasi-static and magnetic induction solutions to calculate how electromagnetic fields penetrate and deposit energy in biological tissue.
The research suggested that thermal safety levels for 1-20 MHz frequencies could be "many orders of magnitude" higher than the 10 mW/cm² microwave standard due to much lower energy absorption rates.
